Scaffold Popups & Bottom Sheets

The Scaffold ships one shared overlay primitive powering popups, bottom sheets, drawers and the tab bar's overflow panel: popups and sheets stack freely in open order, each above its own scrim (the drawer and the tab bar panel are single-instance; the panel's scrim sits below the bar), with consistent back/scrim-tap dismissal — identical on iOS and Android, no platform modals involved.

Popups

IScaffoldPopup popup = await scaffold.ShowPopupAsync(new MyPopupView());

// Then either await the close...
await popup.Closed;          // completes on EVERY close path

// ...OR close it programmatically (also IAsyncDisposable):
await popup.CloseAsync();

ScaffoldPopupOptions (or the equivalent ScaffoldPopup.* attached properties on the view itself — except Anchor, AnchorOffset and CustomPlacer, which are call-site only) control presentation:

Option Purpose
Placement Center (default) or anchor-relative: AnchorBelow, AnchorAbove, AnchorStart, AnchorEnd (dropdowns).
Anchor + AnchorOffset The view the anchored placements are relative to.
CustomPlacer IScaffoldPopupPlacer for fully custom geometry.
Margin Safe-area-aware margin around the placement area.
Scrim Dimming brush (always fades in/out; input-blocking even when transparent).
CloseOnScrimTap / CloseOnBack Dismissal policy (default true).

Declarative flavor — options attached to the view:

<ContentView nalu:ScaffoldPopup.Placement="AnchorBelow"
             nalu:ScaffoldPopup.Scrim="#40000000">

Popups enter with a subtle fade+scale; the content view is measured at its natural size within the placement area — and re-placed whenever that natural size changes after presentation (a deferred image, an expanding section, a loaded list): the popup re-fits and re-centers/re-anchors on its own, nothing to call.

Bottom sheets

A bottom sheet hosting a duration wheel, shown from a page model via IOverlayService

The sample's duration picker: a model-first bottom sheet (IOverlayService) hosting the Nalu.Maui.Controls DurationWheel, closing with a typed result.

await scaffold.ShowBottomSheetAsync(new FilterSheet(), new ScaffoldBottomSheetOptions
{
    Detents = [ScaffoldSheetDetent.Content, ScaffoldSheetDetent.Fraction(0.9)],
    InitialDetent = 0,
    ShowDragHandle = true
});
Option Purpose
Detents Resting heights: Content (natural height), Fraction(0..1), Height(dp).
InitialDetent Index into Detents.
AllowPullDownToClose Drag below the lowest detent dismisses (default true).
ShowDragHandle The standard grabber.
MaxWidth Caps sheet width (centered) — tablets/landscape.
Scrim, CloseOnScrimTap, CloseOnBack As for popups.

Sheets are draggable between detents with native-feeling physics; the sheet handles its own bottom safe-area padding. A Content detent follows the content's natural height live: content that grows or shrinks after presentation re-resolves the detent (the sheet stays bottom-anchored on the detent it rests on). The same ScaffoldBottomSheet.* attached properties exist for declaring options on the sheet view.

Soft keyboard

Sheets and popups hosting text input are keyboard-aware out of the box: by default the keyboard takes room away from the topmost presented sheet or popup (Resize — the sheet pads its content above the keyboard, the popup is re-placed above it), and Scaffold.KeyboardMode on the content (or KeyboardMode in the options) switches to Pan or None. The whole story — pages, sheets, popups, who owns the keyboard, None + MAUI's SafeAreaEdges — lives in Scaffold & the Soft Keyboard.

Tab bar panels

Scaffold.ShowTabBarPanelAsync(View, Brush? scrim, bool closeIfOpened) presents a panel docked above the tab bar while keeping the bar interactive (the scrim covers the page, not the bar) — this is what the default tab bar's overflow "More" uses (see Structure & Tab Bar), available for your own quick-switch panels. ScaffoldTabBar.ShowPanelAsync(...) is the area-level equivalent.

MVVM overlays — IOverlayService

For model-first flows, register overlays and show them without touching views:

builder.UseNaluScaffold(scaffold => scaffold.AddOverlays());

AddOverlays() is source-generated (the generator ships inside the NuGet package): at build time it discovers every class whose public constructor takes IOverlayRef — the model-first anchor — and emits plain AddOverlay<...> calls, AOT/trim-safe:

  • a View-derived class taking IOverlayRef registers view-only (AddOverlay<TView>()): the view is its own lifecycle target, shown via Show*Async<TView>(), its BindingContext left untouched;
  • any other class is an overlay model, paired with the View whose constructor takes the model type (a view assigning it to BindingContext wins ties), or the FooModel → FooView naming convention.

[AutoOverlay] tunes the discovery: opt in a model that doesn't inject IOverlayRef, name the view explicitly with [AutoOverlay(typeof(TheView))] when several match, or opt out with [AutoOverlay(Enabled = false)]. Overlays in other assemblies (which the generator does not scan) register manually — AddOverlay<TModel, TView>(), AddOverlay<TView>() and the view-factory overload all remain available and compose freely with AddOverlays(). Diagnostics NALU0101–NALU0103 flag unresolvable or ambiguous views.

public class ItemsPageModel(IOverlayService overlays)
{
    public async Task DeleteAsync()
    {
        // Model receives the intent; TResult completes when the overlay closes.
        var confirmed = await overlays.ShowPopupAsync<ConfirmDeleteModel, bool>(itemId);
        ...
        await overlays.ShowBottomSheetAsync<FilterSheetModel>();
    }
}

Options can still be passed per call, or declared on the view via the attached properties.

Closing: IOverlayRef

The ref the model (or the view — it is resolvable throughout the presentation scope) injects is exactly two methods, both non-generic:

public interface IOverlayRef
{
    Task CloseAsync();               // caller's task completes with default
    Task CloseAsync(object? result); // caller's task completes with the result
}
  • the result is passed as object? and validated at close time against the TResult the overlay was shown with: a mismatch throws InvalidOperationException, and so does reporting any result at all when the overlay was shown through a resultless overload (Show*Async<TModel>()) — the result-carrying overload is the only one that accepts one;
  • CloseAsync(null) on a TResult presentation completes the caller with default, which is also what every DISMISSAL produces (scrim tap, pull-down, system back, navigation). A model that must distinguish "dismissed" from an explicit empty answer needs a reference TResult wrapper — a bool result cannot tell false apart from a dismissal;
  • closing is legal BEFORE the overlay is presented: a close requested from OnEnteringAsync is buffered and skips the presentation entirely — the caller's task completes without the overlay ever appearing, and ILeavingAware/disposal still run.

Intents: OnEnteringAsync, not the constructor

The intent is NOT a constructor parameter — the model is built by DI first (it can only see IOverlayRef and registered services), then the intent is delivered exactly as the navigation engine delivers it to page models:

  • a single-parameter method named OnEnteringAsync returning ValueTask, whose parameter type the intent is assignable to, is found by reflection and invoked — implementing IEnteringAware<TIntent> is the typed way to declare it (explicit interface implementations match too);
  • when no such overload fits — or no intent was passed — the parameterless IEnteringAware hook runs instead, if implemented;
  • ILeavingAware runs when the overlay closes, then IAsyncDisposable/IDisposable.
public partial class DurationSheetModel(IOverlayRef overlay) : IEnteringAware<DurationSheetIntent>
{
    public ValueTask OnEnteringAsync(DurationSheetIntent intent) { ... }

    private Task Done() => overlay.CloseAsync(new DurationSheetResult(Duration));
}

Scopes

IOverlayService is registered as a singleton (inject it like INavigationService — from page models and from app-wide services alike), over a singleton registry built once inside UseNaluScaffold — the AddOverlay* calls are evaluated at startup, never per presentation. Each presentation creates its own DI scope for the model/view pair, disposed when the overlay closes: it is a fresh scope (a child of the root provider), not a child of the calling page's scope, so page-scoped services are not shared with the overlay — the intent is the channel for what the overlay needs to know.

Keep ONE public constructor per model/view: multi-constructor selection is not service-aware.

While the app is not scaffold-hosted (a non-scaffold navigation host, or a platform without scaffold hosting — see platform support), every call is a graceful no-op returning default immediately.

Options resolution order (popups vs sheets)

Both kinds resolve each option as call-site value ?? the content's attached value ?? default, but they read the attached values at a different moment:

  • a popup is attached to the scaffold's element tree FIRST (when the view has no parent yet) and read AFTER — attached values produced by styles or resources resolved on parenting are seen;
  • a sheet's GEOMETRY options (Detents, InitialDetent, AllowPullDownToClose, ShowDragHandle, MaxWidth) are read BEFORE the content is wrapped in the sheet chrome and attached — they must be literal on the view; only Scrim, CloseOnScrimTap and CloseOnBack are read after attachment.

Pass ScaffoldBottomSheetOptions at the call site when a geometry value is not a literal.

Stack semantics

  • Entries stack freely (popup over sheet over popup); each has its own scrim.
  • System back closes the topmost entry with CloseOnBack = true; entries with CloseOnBack = false consume back without closing.
  • Navigation closes all open overlays before the page swap.
  • Overlay content never self-insets (the scrim covers the whole window uniformly); sheets and panels manage the safe areas that matter for them.

Observing overlays: Scaffold.OverlayEvent

Overlays are not pages: they never appear in Scaffold.NavigationEvent. To observe them (analytics, diagnostics), subscribe to Scaffold.OverlayEvent: one Presented / Closed pair per overlay instance, after the fact, whatever opened or closed it — handle or IOverlayRef, scrim tap, system back, sheet pull-down, navigation, tab bar panel replacement.

OverlayEvent += (_, e) =>
{
    // e.Kind: Popup | BottomSheet | TabBarPanel | Flyout
    // e.EventType: Presented | Closed
    // e.Content: the presented view (for a sheet: your content, not the wrapper)
    // e.Model / e.Intent: IOverlayService overlays only (null for view-level Show*Async / flyouts)
    // e.Result: on Closed, what the model passed to IOverlayRef.CloseAsync(result); null otherwise
    // e.FlyoutSide: Start | End for flyouts
    var name = (e.Model ?? e.Content).GetType().Name;
    _analytics.Track(e.EventType == ScaffoldOverlayEventType.Presented ? "overlay_open" : "overlay_close", e.Kind, name);
};

Guarantees: Presented is raised once the presentation succeeded (for IOverlayService overlays, after OnEnteringAsync; a close requested in OnEnteringAsync skips the presentation and raises nothing); Closed is raised before the model's OnLeavingAsync; a failed presentation raises nothing; replacing the tab bar panel raises Closed for the old content and Presented for the new one.

Full modal pages (with their own navigation stack semantics) are a navigation feature — Scaffold.PageMode — documented in Transitions & Modals.
